  • QDR-365SC高强度LED 紫外线灯

QDR-365SC高强度LED 紫外线灯

Spectroline 的新型QUADRAN™ 365 NDT 灯 (QDR-365SC)具有四个超高通量 UV-A LED 和一个方便的白光 LED,可在荧光检测和缺陷定位之间快速切换。为了提高灵活性,它具有独特的双、高/低白光输出控制。该灯完全符合 LED UV-A 灯的 ASTM E3022 标准。

在线咨询 价格咨询
13818683556
QDR-365SC高强度LED 紫外线灯产品详情

QDR-365SC高强度LED 紫外线灯

QDR-365SCLED高强度紫外线灯已经停产,升级型号为:UV-365ES

http://www.fzyq.cn/ziwaixiantanshangdeng/UV-365EH.html

QDR-365SC配有四个紫外LED及一个白光LED灯泡,大光斑LED UV-A紫外灯,满足ASTM E3022及EN ISO:3059标准

在15"(38cm)距离下名义UV-A紫外强度3700 uw/cm2

在15"(38cm)距离下zui小1200uw/cm2的照射面积达6英寸(15cm)

低白光泄露-小于0.5英尺烛光(5勒克斯)

长寿命UV-A透镜,降低老化速度

随灯带有满足ASTM E3022的证书


Spectroline 的新型QUADRAN™ 365 NDT 灯 (QDR-365SC)具有四个超高通量 UV-A LED 和一个方便的白光 LED,可在荧光检测和缺陷定位之间快速切换。为了提高灵活性,它具有独特的双、高/低白光输出控制。该灯完全符合 LED UV-A 灯的 ASTM E3022 标准。


QUADRAN 的宽波束配置产生了极宽的覆盖区域,使其成为手持和在线应用的理想选择。长效 UV-A 镜片可降低日晒率。该灯在 15 英寸(38 厘米)处具有 3,700 μW/cm2 的标称稳态 UV-A 强度。它还在 15 英寸(38 厘米)处具有 6 英寸(15.2 厘米)直径的大覆盖区域,zui小 UV-A 强度为 1,000 μW/cm2。它的低可见光发射小于 0.5 英尺烛光 ( 5 勒克斯)。


QUADRAN 带有集成黑光过滤器的面板可减少波长超过 400 nm 的输出。而白光 LED 允许扫描表面缺陷或照亮黑暗的工作空间。内置风扇使 LED 保持凉爽,以在长时间使用期间保持zui佳光输出。QUADRAN 配备多 LED 宽光束 UV-A ( 365 nm ) 检查灯。它专为满足 LPT 和 MPT 的 ASTM UV-A 强度和波长规范而设计。


QUADRAN 没有扳机手指疲劳。它会一直工作,直到您完成工作。这是因为切换操作模式就像切换后置、易于使用的三向翘板开关(白光/关闭/紫外线)一样简单。内置的灯柄插针插座可以轻松连接各种 Spectroline® 安装配件,用于在线检测应用(配件单独出售)。


每盏灯都随附一份符合 ASTM E3022 标准的符合性证书,用于 LED UV-A 灯的发射特性和要求。

选择标准的 8 英尺电源线 ( 2.4 m ) 或带有交流插头和橡胶套的超长 20 英尺 ( 6.1 m ) 重型电源线。您还可以选择可选的工业电源或带电线套件的直插式电源(单独出售)。电源和线组均提供 120V、230V、240V 和 100V 型号。每盏灯都配有吸收紫外线的眼镜,并装在一个方便、轻便、柔软的手提箱中。


Spectroline's new QUADRAN™ 365 NDT lamp (QDR-365SC) feature four ultra-hi-flux UV-A LEDs plus a convenient white light LED to quickly switch between fluorescent inspection and flaw location. For increased flexibility, it features a unique dual, high/low white light output control. The lamp is fully compliant with the ASTM E3022 Standard for LED UV-A lamps.


The QUADRAN's broad-beam configuration produces an extremely wide coverage area, making it ideal for both hand-held and in-line applications. Long-lasting UV-A lenses reduce the rate of solarization. The lamp features a nominal steady-state UV-A intensity of 3,700 μW/cm2 at 15 inches (38 cm). It also has a large 6 inch (15.2 cm) diameter coverage area at 15 inches (38 cm), with a minimum UV-A intensity of 1,000 μW/cm2. It’s low visible light emission is less than 0.5 foot-candle (5 lux).


QUADRAN's faceplate with integral blacklight filters reduces output of wavelengths longer than 400 nm. While the white light LED allow for scanning of surface flaws or illuminating dark work spaces. Built-in fans keep the LEDs cool to maintain optimum light output during extended use.  The QUADRAN features multi-LED, broad-beam UV-A (365 nm) inspection lamps. It is specifically designed to meet ASTM UV-A intensity and wavelength specifications for LPT and MPT.


There's no trigger finger fatigue with the QUADRAN. It stays on, working, until you’re done working. That’s because switching operation modes is as simple as toggling the rear-mounted, easy-use, three-way rocker switch (white light/off/UV). A built in lamp handle pin receptacle allows for easy attachment of various Spectroline® mounting accessories for in-line inspection applications (accessories sold separately).


A CERTIFICATE OF CONFORMANCE FOR ASTM E3022 STANDARD FOR EMISSION CHARACTERISTICS AND REQUIREMENTS FOR LED UV-A LAMPS IS SUPPLIED WITH EACH LAMP.


Choose between the standard 8 foot cord (2.4 m) or the extra-long 20 foot (6.1 m) heavy-duty power cord that comes with an AC plug and rubber boot. You can also choose between the optional industrial power supply or in-line power supply with cord sets (sold separately). All power supply and cord sets are available in 120V, 230V, 240V and 100V models. Each lamp comes with UV-absorbing spectacles and is packed in a convenient, lightweight, soft carrying case.
